BRIG FALCON - GENERAL VIEW of the BOATS

2385.01-2020
— 11 —
Boat General View (see Fig.1).
1 - Inflatable tube with Inflation valve
2 - Rigid bottom
3 - Transom with engine mounting plate
4 - Hangles
5 - Oarlock
6 - Oars and oars holder
7 - Bow lifting eyes
8 - Rear lifting eyes
9 - Wooden seats
10 - Drain valve
11 - Rubbing strake
12 - Carrying handle
13 – Towing bow eyes
GENERAL VIEW of the BOATS.
Fig.1
1
12
5
12
13
11
4 2 6 9
7
10
3
7
