— 16 —
Tender Container for DeLuxe and Tender Deluxe Versions.
Tender Container is intended for placing of two passengers and for installation of storage battery, oars etc.
They may be mounted on the rigid deck of the “BRIG” boats F300, F330, F360 Deluxe and Tender Deluxe versions and other boats.
Tender Container includes: the locker, soft seat and lock to fixing the sat (see Fig.8).
I
n order to install the container to the BRIG boat perform the next operations (see Fig. 8):
• hinge out the seat;
• fix the cntainer by means of the bolt M8 and washers to the deck boat;
• replace the seat.
130
430
Fig.8
Tender Container
Locker
Soft seat
340
550
225
660
760
Bottom view
