BRIG FALCON - Steering Console; Steering Console for Deluxe and Tender Deluxe Versions

— 14 —
STEERING CONSOLE.
Steering console Tender Luxe is intended for mounting steering system and remote control system.
The console may be installed on the BRIG boats F300, F330 and F360 Deluxe and Tender Deluxe versions.
The Steering console consists of the following main components (Fig.5):
• console body, that comprises the overhead part (2), hinged with lower part (1).
• cushion (3);
• lock (4);
• wire type steering grommet (5).
Steering Console for DeLuxe and Tender Deluxe Versions.
TENDER DELUXE version Boat General View (see Fig.4).
1 - Inflatable tube
2 - Inflation valves
3 - Rigid bottom with transom
4 - Outboard engine mountingplate
5 - Tender luxe console
6 - Tender container
7 - Bow and rear lifting eyes
8 - Bow plate with navigation lights
9 - Handles
10 - Tube hard end
11 - Rubbing strake
12 - Carrying handle
13 – Towing bow eye
Fig.4
1
2 3
4
5
7
6
8
9
10
11
12
13
7
