BRIG FALCON - Page 13

2385.01-2020
— 13 —
SPORT version Boat General View (see Fig.3).
1 - Inflatable tube
2 - Inflation valves
3 - Rigid bottom with transom
4 - Outboard engine mountingplate
5 - Sport console
6 - Bow lifting eyes
7 - Rowlock
8 - Handles
9 - Rear lifting eyes
10 - "BRIG" label
11 - Rubbing strake
12 - Carrying handle
13 - Oar stowage
14 - Oar
15 - Towing bow eye
16 - Drain valve
17 - Bow plate with navigations lights
1 2 3
4
5
6
7
8
9
10
11
12
15
14
13
Fig.3
16
17
