12
The neck is adjustable in all directions up to 30° and is secured with a locking nut. The locking
nut should only be tightened by hand and excessive torque should be avoided. The volume is
adjustable from 70 to 90dB, measured at 1m distance.
Function
Location
Zone Lights or Status
Light Flash Frequency
Buzzer Alert
Interval
System off
(Not powered)
Status Light
Off
off
Power Cycle required after:
New Sensor connected
(Higher priority over system
configuration)
Status Light
Alternating between red /
green 0.5 second each
Constant for
0.5 seconds,
repeated in
5 seconds
System power on Self-Test
(After applying power supply)
6m length x 4.5m width
selected
Green & Yellow &
Orange & Red Zone
Lights
Constant for 1 second
Constant for
1 second
Light Green Zone
Lights
Constant for 3 seconds
Status Light
Red / Constant for
5 seconds
System power on Self-Test
(After applying power supply)
4.5m length x 3.5m width
selected
Green & Light Green &
Orange & Red Zone
Lights
Constant for 1 second
Constant for
1 second
Yellow Zone Lights
Constant for 3 seconds
Status Light
Red / Constant for
5 seconds
Volume Control
(Right Hand Side)
Status Light
Green Zone Light
Furthest Detection Zone 5
Buzzer Output
(Underneath)
Locking Nut
Self-adhesive Pad
Red Zone Light
Closest Detection Zone 1
Light Green Zone Light
Detection Zone 4
Yellow Zone Light
Detection Zone 3
Orange Zone Light
Detection Zone 2
