Function
Location
Zone Lights or Status
Light Flash Frequency
Buzzer Alert
Interval
System power on Self-Test
(After applying power supply)
3m length x 2.5m width
selected
Green & Light Green &
Yellow & Red Zone
Lights
Constant for 1 second
Constant for
1 second
Orange Zone Lights
Constant for 3 seconds
Status Light
Red / Constant for
5 seconds
System Standby (After Self-
Test)
Status Light
Amber / 1 second on, 1
second off
Off
At the point of system
activation and no object
detection
(When activation input is
applied)
Status Light
Green / Constant
0.2 second on,
0.2 second off,
0.2 second on,
off
System Active and no object
detection
(After activation is applied via
activation input)
Status Light
Green / Constant
off
Detection in Zone 5
(Furthest Detection Zone)
Green Zone Light
Constant
1.5 times per
second
Detection in Zone 4
Green & Light Green
Zone Lights
Constant
2 times per
second
Detection in Zone 3
Green & Light Green &
Yellow Zone Lights
Constant
2.5 times per
second
Detection in Zone 2
Green & Light Green &
Yellow & Orange Zone
Lights
Constant
3 times per
second
Detection in Zone 1
(Closest Detection Zone)
Green & Light Green &
Yellow and Orange
Zone Lights
Constant
Constant
Red Zone Light
0.5 second on, 0.5
second off
System/Sensor Error occurred
with System Active
All Zone Lights
Constant for 5 seconds
Constant for
5 seconds
Status Light
Red / 1 time per second
System/Sensor Error with
System Active
Status Light
Red / 1 time per second
0.5 seconds,
repeated in
5 seconds
System/Sensor Error with
System Standby
Status Light
Red / 1 time per second
off
System Error - Mode1 and
Mode2 Status Changed while
System Power ON
All Zone Lights
Constant
0.5 seconds,
repeated in 10
seconds
Status Light
Red / 1 time per second
