8 www.brutepower.com
Install Wheel Kit
NOTICE Wheel kit is not intended for over-the-road
use.
Install the wheel kit as follows:
1. Lift corner of pressure washer and slide caster
wheels up into bottom of tubing on each
underside of pressure washer frame.
2. Using a 19 mm wrench, turn nut (A) under collar of
caster wheels to tighten.
3. Slide at washer (B), wheel (C) and another at
washer (B) over axle stud (D).
NOTICE Be sure to install wheel with raised hub
inboard.
4. Lift corner of pressure washer slightly and slide
axle stud through mounting bracket on pressure
washer frame.
5. Insert retaining pin (E) through hole on axle stud.
6. Repeat steps 3 through 5 to secure second wheel.
Moving Pressure Washer
The pressure washer is equipped with a handle
that locks into three dierent positions for your
convenience. With the handle in the upright position,
it makes it easy to push or pull your pressure washer
to the desired location. With the handle in the middle
position, you can tilt the pressure washer back. The
handle also folds down at for storage.
1. Screw handle pin (F) into bracket on left side of
frame (viewing pressure washer from engine end).
2. Pull handle pin out and lift handle to desired
position.
3. Release handle pin and make sure latch (G) locks
into place.
4. Place lock levers on caster wheels in the OFF
(0) postion to unlock wheels and move pressure
washer to desired location.
NOTICE Always face pressure washer and push or
pull to desired location. When moving pressure washer
on an incline, always make sure you are uphill from
pressure washer.
5. Place lock levers on caster wheels in the ON (I)
postion to lock wheels and keep pressure washer
from moving.
F
G
B
E
C
D
A
