33
Briggs & Stratton Power Products Home Standby Generator
Installation, Start-Up and Owner’s Manual
PARTS LIST - CONTROL PANEL
Item Part # Description
1 195229GS ASSY, Control Box
2 195227GS ASSY, Panel, Control
3 195225GS PANEL, Back Cover
4 195004GS KIT, Control Board w/ Clips
5 195003GS KIT, Battery Charge Circuit w/ Clips
6 190818EGS BREAKER, Circuit, 30A
7 87799GS SWITCH, Rocker
8 * SCREW, #10 x 5.8"
9 * WASHER, Shakeproof #6
10 * PPHMS, #6 - 32 x 3/8"
11 193423GS SWITCH
12 195006GS KIT, Fuse Holder w/ Fuse
13 192455GS BUSHING, Snap 5/8"
14 186173GS BUSHING, Snap 1-3/8"
15 186582GS BUSHING, Snap 7/8"
16 195007GS KIT,Wire Harness with Crimp Nut
17 * HHCS, M6 - 1.0 x 30
18 195009GS KIT, Plastic Clips
19 * SCREW, 12 -24 x 1/2 Thd Forming
20 * WASHER, Shakeproof
21 * BOLT, Swage, 1/4 - 20 x 1/2
22 193171GS ASSY,Wire
23 691656 CONTACTOR, Starter
24 194659GS ASSY,Wire
25 194251GS KIT, Hardware Starter Contact
26 188573AGS ASSY,Wire, Series w/2 Ring Lug
27 194250GS KIT, J-Bolt/Strap with Hardware
28 193347GS KIT, Battery Hardware
29 188443GS BATTERY
30 193291GS REGULATOR, Fuel
31 186151GS FITTING, Elbow, 3/4 NPT
32 186148GS HOSE, Gas, Reg. to Valve
33 186150GS FITTING, Elbow, 3/8 NPT
34 195005GS KIT, Hose, Reg to Engine with Clamps
35 193537CGS ASSY,Wire
36 192449GS FITTING, Nipple, 3/4 x 2
37 B4773GS SOLENOID, Gas Fuel
38 186646GS DECAL,Warning,Auto Start
39 186647GS DECAL,Warning, Outdoor Install
40 190992GS DECAL,Warning Electrical Shock
41 186645GS DECAL, Caution, Shock
42 195306GS DECAL, Set Exercise Timer
43 B4986GS DECAL, Ground
44 * NUT, M6 - 1.0
45 * WASHER, Lock, 1/4
46 186641GS DECAL, Operating Instructions
47 * SCREW, 10 x 32 x 1 Phillips Truss Head
* - Items without part numbers are common fasteners and are available at local hardware stores.
