Problem
Cause
Solution
Engine is running, but no
AC output is available.
1. Generator circuit breaker is open.
2. Poor wiring connections or
defective transfer switch.
3. Transfer switch circuit breaker
open or defective.
4. Fault in generator.
1. Reset circuit breaker.
2. Check and repair.
3. Reset or replace circuit breaker.
4. Contact Briggs & Stratton service facility.
Engine runs good but
bogs down when loads
are connected.
1. Short circuit in a connected load.
2. Generator is overloaded.
3. Engine speed is too slow.
4. Shorted generator circuit.
1. Disconnect shorted electrical load.
2. See “Essential Circuits” on page 6.
3. Contact Briggs & Stratton service facility.
4. Contact Briggs & Stratton service facility.
Engine will not start; or
starts and runs rough.
1. Rocker switch set to “Stop”.
2. Fuel valve is in “Off” position.
3. Dirty air cleaner.
4. Out of gasoline.
5. Stale gasoline.
6. Spark plug wire not connected to
spark plug.
7. Bad spark plug.
8. Water in gasoline.
9. Overchoking.
10. Low oil level.
11. Excessively rich fuel mixture.
12. Intake valve stuck open or closed.
13. Engine has lost compression.
14. Failed battery.
1. Set switch to “On”.
2. Turn fuel valve to the “On” position.
3. Clean or replace air cleaner.
4. Fill fuel tank.
5. Drain gas tank and fill with fresh fuel.
6. Connect wire to spark plug.
7. Replace spark plug.
8. Drain gas tank; fill with fresh fuel.
9. Put choke lever at “Run” position.
10. Fill crankcase to proper level.
11. Contact Briggs & Stratton service facility.
12. Contact Briggs & Stratton service facility.
13. Contact Briggs & Stratton service facility.
14. Replace battery.
Engine shuts down
during operation.
1. Out of gasoline.
2. Low oil level.
3. Fault in engine.
1. Fill fuel tank.
2. Fill crankcase to proper level.
3. Contact Briggs & Stratton service facility.
Engine lacks power.
1. Load is too high.
2. Dirty air filter.
3. Engine needs to be serviced.
1. See “Essential Circuits” on page 6.
2. Replace air filter.
3. Contact Briggs & Stratton service facility.
Engine “hunts” or
falters.
1. Choke is opened too soon.
2. Carburetor is running too rich or
too lean.
1. Move choke to halfway position till
engine runs smoothly.
2. Contact Briggs & Stratton service facility.
TROUBLESHOOTING

Briggs & Stratton Home Generator System Specifications

Electrical Specifications

rated maximum load current at 25°C/77°F, LP	83.3 Amps
rated AC voltage	240 Volts
phase	Single phase
rated frequency	60 Hertz

Operating Environment

normal operating range	-20°F (-28.8°C) to 104°F (40°C)
output sound level at normal load	68 dB(A) at 23 ft. (7 m)

Weight and Dimensions

shipping weight	575 lb (260 kg)
