Clutch/Brake - 7028514
Shows operation of Clutch/Brake pedal. Depress
Clutch/Brake pedal to disengage clutch and apply
brake.
Park Brake - 7103219
Shows operation of park brake latch. Refer to “Setting
the Park Brake”.
Reverse Lockout Override - 7104796
Identifies location of Reverse Lockout Override Lever.
Refer to “Reverse Lockout Mechanism”.
WARNING
Do not mow in reverse unless absolutely necessary.
!
!
Height of Cut - 7103440
Identifies height of cut positions. Refer to “Cutting
Height Adjustment”.
Blade On/Blade Off - 1760758
Shows operation of mower blade. Refer to “Engaging
the Mower Blade” and “Stopping the Engine, Wheel
Drive and Mower Blade”.
