1
Note: (This note applies only to engines used in the U.S.A.) Maintenance, replacement or repair of the emission control devices and systems may be performed
by any nonroad engine repair establishment or individual. However, to obtain no charge repairs under the terms and provisions of the Briggs & Stratton
warranty statement, any service or emission control part repair or replacement must be performed by a factory authorized dealer.
How To Use Manual Figures
− refer to figures inside covers.
− refer to engine components in figure
.
− refer to part/action in figures.
19
1
Record your engine
Model, Type and Code numbers
here for future use.
Record your date of purchase here for future use.
Technical Information
Engine Power Rating Information
The gross power rating for individual gas engine mod-
els is labeled in accordance with SAE (Society of Auto-
motive Engineers) code J1940 (Small Engine Power &
Torque Rating Procedure), and rating performance has
been obtained and corrected in accordance with SAE
J1995 (Revision 2002-05). Torque values are derived
at 3060 RPM; horsepower values are derived at 3600
RPM. Actual gross engine power will be lower and is af-
fected by, among other things, ambient operating con-
ditions and engine-to-engine variability. Given both the
wide array of products on which engines are placed
and the variety of environmental issues applicable to
operating the equipment, the gas engine will not devel-
op the rated gross power when used in a given piece of
power equipment (actual on-site" or net power). This
difference is due to a variety of factors including, but not
limited to, accessories (air cleaner, exhaust, charging,
cooling, carburetor, fuel pump, etc.), application limita-
tions, ambient operating conditions (temperature, hu-
midity, altitude), and engine-to-engine variability. Due
to manufacturing and capacity limitations, Briggs &
Stratton may substitute an engine of higher rated pow-
er for this Series engine.
Engine Components (see fig. )
1
Engine Model Type Code
xxxxxx xxxx xx xxxxxxxx
2
Governor control lever
3
Air cleaner
4
Rope handle
5
Finger guard
6
Muffler/spark arrester, if equipped
7
Spark plug
8
Primer bulb
9
Carburetor
10
Fuel fill
11
Fuel tank
12
Flywheel
13
Oil fill/Dipstick
Hazard Symbols and Meanings
Explosion
Toxic Fumes
Moving Parts
Shock
Hot Surface
Kickback
Fire
International Symbols and Meanings
On Off
Fuel Shutoff
Read Owner’s
Manual
Stop
Fuel
ChokeSafety Alert
Oil
Safety Precautions
* Briggs & Stratton does not necessarily know what
equipment this engine will power. For that reason,
you should carefully read and understand the oper-
ating instructions for the equipment on which your
engine is placed.
BEFORE OPERATING ENGINE
• Read entire Operating & Maintenance Instructions
AND the instructions for the equipment this engine
powers.*
• Failure to follow instructions could result in serious inju-
ry or death.
THE OPERATING & MAINTENANCE INSTRUC-
TIONS CONTAIN SAFETY INFORMATION TO
• Make you aware of hazards associated with engines
• Inform you of the risk of injury associated with those
hazards, and
• Tell you how to avoid or reduce the risk of injury.
The safety alert symbol is used to identify safety
information about hazards that can result in personal injury.
A signal word (DANGER, WARNING, or CAUTION) is used
with the alert symbol to indicate the likelihood and the potential
severity of injury. In addition, a hazard symbol may be used to
represent the type of hazard.
DANGER indicates a hazard which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazard which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazard which, if not avoided,
might result in minor or moderate injury.
CAUTION
, when used without the alert symbol, in-
dicates a situation that could result in damage to
the engine.
The engine exhaust from this product contains
chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.
WARNING
