Brighter Smart 1000 - DMX Channels

10
 STROBE: range for 0 to 255
5. Set light run parameters
 Enter the page, set the parameter of light:
 Pan Invert: Reverse PAN move.
 Tilt Invert: Reverse TILT mover.
 Rectify enable：set as ‘OFF’, PAN or TILT will disable position rectify function.
 As ‘ON’, when PAN or TILT lose steps, light will rectify auto.
 Pan Offset: Set PAN original position.
 Tilt Offset: Set TILT original position.
 Lamp up when: Select lamp on mode, includes 3 mode: “power on”, “after reset done” and
“manual”.
 Factory setting: restore all parameter to factory setting.
6. View status
 View light current status, version；
 DMXClr: Click to clear all DMX data to ‘0’.
 SysRst：Click to reset light.
9. DMX Channels
CH NO
Name
value
Function
CH1
X
0-255
Pan movement by 540°
CH2
Y
0-255
Tilt movement by 270°
CH3
XY speed
0
Max. speed (tracking mode)
1-255
Speed from max. to min. (vector mode)
CH4
power/macro
0-129
empty
130-139
Lamp On,reset(total reset except pan/tilt reset)
140-149
Pan/Tilt reset
150-189
Effect motor reset
190-199
Reserved
200-209
Total reset
210-229
Reserved
230-239
Lamp Off
240-255
Reserved
CH5
Color wheel
0-8
Open/white
9-17.
Deep Red
