Brighter Smart 1000 - Page 15

15
CH15
shutter
0-31
Shutter closed ( Lamp power reduced to 230 W)
32-63
Shutter open, Full lamp power
64-95
Strobe-effect from slow to fast
96-127
Shutter open
128-143
Opening pulse in sequences from slow to fast
144-159
Closing pulse in sequences from fast to slow
160-191
Shutter open
192-223
Random strobe-effect from slow to fast
224-255
Shutter open, Full lamp power
CH16
dimmer
0-255
Dimmer intensity from 0% to 100%
24 channel mode
CH no
Name
Value
Function
CH1
X
0-255
Pan movement by 540°
CH2
X fine
0-255
Fine Pan
CH3
Y
0-255
Tilt movement by 270°
CH4
Y fine
0-255
Fine Tilt
CH5
XY speed
0
Max. speed (tracking mode)
1-255
Speed from max. to min. (vector mode)
CH6
power/macro
0-129
empty
130-139
Lamp On, reset(total reset except pan/tilt reset)
140-149
Pan/Tilt reset
150-189
Effect motor reset
190-199
Reserved
200-209
Total reset
210-229
Reserved
230-239
Lamp Off
240-255
Reserved
CH7
gobo
0-8
Open/white
9-17.
Deep Red
18-26
Deep Blue
27-36
Yellow
37-45
Green
46-54
Magenta
55-63
Azure
64-72
Red
73-81
Dark green
82-90
Amber
