III. Performance properties
Performance properties of a monoblock-type heat pump for swimming pools
Code THP 55 THP 100 THP 120 THP 170
Nominal heat output
W 5500 9900 11800 17300
BTU 19000 34000 41300 59500
Heat input W 1240 1940 2650 3670
Operating current for heating A 5,5 9,6 13,3 18
Current supply V/phase/Hz 220-240/1/50
Number of compressors 1 1 1 1
Compressor
Scroll
Number of ventilators 1111
Input of ventilators W 25 50 50 50
Ventilator speed RPM 950 950 950 950
Noise dB(A) 53 55 57 59
Mains pipe mm 50 50 50 50
Water fl ow m
3
/h 2-4 4-6 6-8 8-10
Decrease in water pressure kpa 20 20
20 20
Coolant (R407C) kg 0,8 1,3 1,3 2,1
Net dimensions
L
mm
935 1090 1090 1165
W 360 370 370 470
H 550 615 615 685
Packaged dimensions
L
mm
1060 1140 1140
1195
W 380 400
400 485
H 600 660
660 730
Weight
net
kg
40 62 65 99
gross 48 71 77 104
