7. Operation logic
7.1 The heating operation logic
Working status Working mode Water in temperature Heat pump working level
1
Start-up of heat
pump
Smart
<
=
setT - 1 Powerful
2 setT - 1 < a < setT + 1 Smart
3
>
=
setT + 1 Standby
4
Silent
<
=
setT - 1 Smart
5 setT - 1 < a < setT + 1 Silent
6
>
=
setT + 1 Standby
7
Powerful
< setT + 1 Powerful
8
>
=
setT + 1 Standby
9
Re-start to heat
water in standby
status
Smart
> setT - 1 Standby
10 setT - 3 < a
<
=
setT - 1 Smart
11
<
=
setT - 3 Powerful
12
Silent
> setT - 1 Standby
13 setT - 3 < a
<
=
setT - 1 Silent
14
<
=
setT - 3 Smart
15 Powerful
<
=
setT - 1 Powerful
7.2 The Cooling operation logic
Working status Working mode Water in temperature Heat pump working level
1
Start-up of heat
pump
Smart
<
=
setT - 1 Standby
2 setT - 1 < a < setT + 1 Smart
3
>
=
setT + 1 Powerful
4
Silent
<
=
setT - 1 Standby
5 setT - 1 < a < setT + 1 Silent
6
>
=
setT + 1 Smart
7
Powerful
> setT + 1 Powerful
8
<
=
setT + 1 Standby
9
Re-start to cool
water in standby
status
Smart
>
=
setT + 1 a < setT + 3 Smart
10
>
=
setT + 3 Powerful
11
Silent
>
=
setT + 1 a < setT + 3 Smart
12
>
=
setT + 3 Powerful
13
Powerful
>
=
setT + 1 Powerful
14 Standby
NOTE :
setT = Setting water temperature
setT-1 = less 1°C than Setting temperature
setT+1= more 1°C than Setting temperature
NOTE:
 Water temperature rise k Water temperature drop
