21
No. Part name No. Part name
1 Top cover 26 Wiring terminal
2 Rear grille 27 Intake valve
3 Vaporiser 28 Pressure gauge
4 Insulation plate 29 Blue sealing lip
5 PFC coil 30 Cover for wiring power supply
6 Pillar 31 Watertight box
7 Fan motor handle 32 Red sealing lip
8 Side grille 33 Regulator
9 Fan motor 34 Flow switch
10 Base 35 Copper pipes
11 Lead 36 High pressure switch
12 Drainage stopper 37 Low pressure switch 1
13 PC inverter board 38 Low pressure switch 2
14 Regulator box cover 39 Filter
16 Regulator box 40 Temperature sensor handle
17 Distribution board 41 4-way valve
18 Front panel 42 Rear panel
19 Fan blade 43 Electronic expansion valve
20 Fan grille 44 Ambient temperature sensor handle
21 Tank for liquid 45 Discharge water connection nut
22 Compressor 46 Water supply connection nut
23 Titanium exchanger
24 Terminal block
25 5-position electric terminal
