Choose a good, cleared assembly
area and get a friend to help you put
your grill together. Lay cardboard
down to protect grill finish and
assembly area.
Step 1
With the help of a friend, turn the
preassembled cart over. Try to
minimize the stress to the bottom
plate.
Step 2
Attach locking casters to the bottom
of the left side cart panel. Tighten
caster bolts securely using hex nut
wrench provided in parts pack.
Step 3
Install the wheels as illustrated, by
inserting the wheel axle bolts
through the wheels, washers and
right side panel axle holes. Tighten
axle bolts securely using hex nut
wrench provided in parts pack.
20
Leg
Tire
Washer
Wheel axle
bolt
Hubcap
Locking Caster
To Next Page
