Step 8
Attach smoker lid to smoker body using
two hood hinge bolts and cotter pins.
Step 9
Attach lid handle to smoker lid using two
M5 X 10 mm bolts.
Step 10
Insert the temperature gauge, and then
turn it clockwise to lock into place.
8
Hood Hinge Bolt
M5 X 10 mm Bolts
Cotter Pin
