Parts List Continued
2 10 x 8 mm hexagonal nuts
2 Door locking plates
2 Door handles
2 Upper hinges
2 Lower hinges
4 6 x 5 mm hexagonal nuts
4 6 x 45 mm Phillips head bolts
16 6 x 12 mm Phillips head bolts
2 Hitch pins
2 Hood pivot pins
8 6 x 28 mm Phillips head bolts
4 8 x 7 mm hexagonal nuts
2 Towel racks
1 Hex nut wrench
13
12
11
10
9
8
7
6
5
4
3
2
1
14
6
7
9
10
11
1 2 3
4
5
8
14
12
13
