Choose a good, cleared assembly area and get a
friend to help you put your grill together. Lay
cardboard down to protect grill finish and
assembly area. Turn the grill on its side to begin
assembly.
Step 1
Insert door handle through hole in door with
handle pointing down. Place door locking plate
over door handle pointing up and secure with a
10 x 8 mm hexagonal nut.
Step 2
Attach steel casters to bottom of each leg.
Tighten caster bolts securely.
Step 3
Align the holes in the right back leg bracket with
the holes in the body of the grill. Insert two
6 x 12 mm Phillips head bolts through the leg
bracket and secure to the grill body.
Step 4
Hang a shelf onto the lower stud of the leg that
you have attached to the grill body.
Locking
Casters
Legs
Door
Handle
Door
Locking
Plate
Nut
Door
Right Back Leg6 x 12 mm Bolts
