Choose a good, cleared assembly
area and get a friend to help
you put your grill together. Lay
card board down to protect grill
finish and assembly area.
CAUTION: Some parts may
contain sharp edges.
Wear protective gloves
if necessary.
Step 1
Attach casters to the bottom of cart
base using sixteen M6 X 12 mm
bolts (black) and sixteen star
washers as illustrated.
Step 2
Lock the caster and use six
M6 X 12 mm bolts (black) and six
star washers to attach the left and
right side cart panels to the cart
base.
Step 3
Use eight M6 X 12 mm bolts
(black) and eight star washers to
attach the cart corner brackets to
the cart base and the cart side
panels.
