Step 15
Place the side burner grate onto
the side burner table.
Step 16
Attach the tank heat shield
under the grease tray using
two M4 X 10 mm bolts (silver).
Step 17
Slide the grease try onto the tracks
located behind and underneath the
grill body assembly.
Step 18
Hang grease cup from the grease
tray. Make sure to slide cup onto
tracks as illustrated.
29
Grease
Tray
Tank Heat Shield
Grease Cup
Side Burner
Grate
To Next Page
