11
Step 19
Attach grill lid handle (item #23) using
two M6 x 12mm Phillips head bolts and
M6 nuts.
Step 20
Install grill lid (item #17) on grill base
(item #9) using two M8 x 23mm Phillips
head shoulder bolts.
Step 21
Attach the charcoal tray (item #12) to
charcoal grate (item #13) by hooking tray
edges onto grate frame.
