ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE
ASSEMBLING OR OPERATING YOUR SMOKER.
FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 1-800-527-0717.
(Proof of purchase will be required.)
Inspect contents of the box to ensure all parts are included and undamaged.
3
Tools required to assemble your
Gourmet Charcoal Smoker and Grill:
• Flathead Screwdriver
• Pliers
PARTS LIST:
1 Dome Lid
1 Smoker Body
2152" Chrome Cooking Grills
1 Porcelain Water Pan
1 Base Pan
1 Charcoal Pan
1 Door
1 Door Hinge
3 Metal Brackets for Handles
6 Wooden Handle Halves
6 Support Brackets
1 Heat Indicator
12 10-24 x s" Screws and Square Nuts
6 6-32 x 4" Screws and Nuts (for Door)
6 8-32 x w" Screws and Nuts (for Handles)
1 Recipe Booklet
Wood Chunk (sample)
