Brinly PP-1200 - Assembly

"X"
FIG. 2
·'HO LE "z"
I-..."':lo_-B
II
L... .lr
II
I'
I
2" ~~a~~o~~~~~~ 1 w~~ ~ out
~->-rt-+'*-J"i~ (w ide tread)
approx
. 30" Inside dim.
between tires.
Beam posit ion with
Tractor Wneels set In
(narrow tread)
approx. 21" ins ide dim.
between tires.
L
'HOLE " X"
-Holes x-x for Tractor.
equipp~d with
8.00 x 15" tir .. .
··Hoies z-z for Tractors
equipped witn
B.OO x 12" tlr ...
ASSEMBLY
FIG. 1. Secure lands ide (A) to frog (B), as shown , with two
%" x 1" plow bo lts and two 'W' hex nuts. FINGER
TIGHTEN .
Next, mount brace (C) between moldboard (D)
and landside (A). Secure with %" x 1" p low bolts and %"
hex nuts . TIGHTEN ALL BOLTS SECURELY. Assemble
standard assembly (E) to plow bottom (w ith %" x2W' land
adjusting bolt (F) and square nut (G) in place) and secure
with W' x 1 Y2 " carriage bolt (H) and hex nut (I) through
top hole and Y2" x 2" plow bol t and hex nut thro ugh reo
main ing hole in landside, frog, and standard. TIGHTE N
SECURELY. Pos
it ion beam assembly (J) over standard, as
shown , and secure with two W ' x 2Y2" hex bolts (K), lock
washers (L). and hex nuts (M).. TIGHTEN SECURELY.
FIG.l
FIG . 3. A. Insert sta~dard (1) into hub on fork (2), (with
forks angling downward). Secure assembly with the 5/1 6"
x 1
W ' roll pin (3), with equal amount of pin extend ing from
each side of hub .
B.
t} sse mb le hub (4) to coulter blade (5), using three 5/1 6"
x
1" carriage bolts (6). flat washers (7). and hex lock nuts
(8).
C.
Attach fork assembly to cou lter us ing axle (9 ), ( wit h
square head insert ed into the
hole in fork) through co ulter
hub. Add flat washers (10) and secure with cotter pin (11 ),
bending legs of pin over to secure assembly .
FIG.
2. Assemb le beam ass.embly (A) to mas t (B), us ing (2 )
"U " bolts (C) (sad dli ng square tube on mas t), (2 ) %" lock
washers (0 ). and (2) %" hex nu ts IE). IF REAR TRACTOR
WHEELS ARE SET IN
NARROW TREAD POSIT ION,
ASSEMBLE IN POSITION
SHOWN. If wheels are set in w id e
tread
position , assemble as sketched in. (Se e w idth of cut
instruct ions in operat ion section of manual ). Inse rt mas t
spacer
(F) between mast upper arms (in bott om hole),
secure
with }fa" x 2W' hex bolt (G), %" lock w asher (H). and
%" hex nut (J).
Assemble lower link pins (K) in holes x-x of mast (for trac-
tors equipped with 8.00 x 15" tires or larger) or ho les z-z
(for tractors equipped with 8 .00 x 12" tires ). Securewit h %"
hex jam
nut (l) (outside). }fa" lock washe r (M), and %" hex
nut.
D.
Mount the completed assemb ly to the left side of p low
beam using coulter clamp (12), U-bolt (13) . spacer (14) .
Insert spacers between beam halves and secure using the
%" hex regular nuts (15) . Refer to coulter adj ustment for
proper coulter se tt ing. T ighten nuts securely .
