ASSEMBLY
Assembly Step 17-C
Assembly Step 18
Wrap the 12’ Hose (27) around
the tank (3).
Connect the sprayer to your
tractor using the hitch.
Measure and adjust the
nozzles to keep a distance
of 17 1/4” from the ground.
Snap the
Sprayer Wand (37)
in place, utilizing the
Wand Bracket (18)
that was added
on Step 9.
Attaching the Wand
Adjusting the Nozzles
NOTE: At each end of the tank
there is a hooked recess where the
hose can rest.
37
18
37
27
17 1/4”
English Manual
