BRISTELL S-LSA - 7.13 Instruments and Avionics

7-8
Date of Issue: 01/2016
Document No.: LSA-AOI-2-1-0-CL
Revision: -
7.13 Instruments and Avionics
BRISTELL S-LSA S/N 317/2018 is fitted with:
1. Back-up ALT Winter 4 FGH 40
2. Back-up ASI Winter 7FMS 513 (0-160 kts)
3. Back-up variometer BC6 (+/- 2000 f)
4. Airpath C2400 L4P Compass
5. Garmin G3X flight display system including:
6. Garmin GDU 460 dual displays
7. Garmin GEA 24 Engine Interface Module
8. Garmin GMA 240 digital audio panel
9. Garmin GMU 22 Magnetometer
10. Garmin GNC 255A NAV/COM
11. Garmin GSU 25 ADHRS (1x)
12. Garmin GTP 59 Temperature Probe
13. Garmin GA 26C GPS antenna for G3X
14. Garmin GAP 26 angle of attack unheated probe
15. TCW IBBS-12V-3AH backup battery for Garmin G3X
16. Garmin GTR 20 remote-mount comm radio
17. Garmin GTX 23 ES mode S transponder
18. ELT Kannad AF Integra 406 MHz + RC 200 control unit
NOTE
For operating instructions refer to the documentation supplied with the
instruments.
