8
Britax Child Safety, Inc.
Rear-Facing Installation
Lap-Shoulder Belt Installation (Preferred Method)
1. Open the CLICKTIGHT.
a. Press the dimple on
the CLICKTIGHT
dial.
b. Rotate dial clockwise
until CLICKTIGHT
releases and lift to
open.
2. Attach the anti-rebound
bar, if included (see page
27).
3. Recline the unoccupied
child seat and place rear
facing on the vehicle
seat. Ensure that no more
than 3 in. (7.6 cm) of the
base hangs over the edge
of the vehicle seat (see
pages 25-26).
4. Slide both the lap and
shoulder parts of the
vehicle belt into the rear-
facing belt slots.
5. Ensure the vehicle belt is
not twisted and buckle
the seat belt.
NOTE: It is not necessary
to lock the lap-shoulder
belt when installing with
CLICKTIGHT.
6. Remove slack from the
lap part (a), then the
shoulder part (b) of the
vehicle belt.
1b
1a
5b
5a
3”
