10
Britax Child Safety, Inc.
1. Open the CLICKTIGHT.
a. Press the dimple on
the CLICKTIGHT
dial.
b. Rotate dial clockwise
until CLICKTIGHT
releases and lift to
open.
2. Attach the anti-rebound
bar, if included (see page
27).
3. Recline the unoccupied
child seat and place
rear-facing on the vehicle
seat. Ensure that no more
than 3 in. (7.6 cm) of the
base hangs over the edge
of the vehicle seat (see
pages 25-26).
4. Remove the lower
connectors from the
storage compartment at
the rear of the seat and
pull the strap to full length
toward the child’s left
side.
5. Slide the lower connector
strap into the rear-facing
belt slots and firmly press
the lower connectors
over their adjacent lower
anchors.
– Verify that the
connectors are secure
and the strap is not
twisted.
Lower Anchor Installation
IMPORTANT:
Do not install rear facing with lower
anchors for a child weighing more than:
– ADVOCATE: 30 lbs (13.6 kg)
– BOULEVARD: 35 lbs (15.8 kg)
1b
1a
3”
To Next Page
