Britax Brook - Adjusting the Harness

18
1. Press and hold both buttons on
either side of the foot rest hinge
while raising or lowering the foot
rest to the desired position.
1. Align the tongues on the hip
straps with the retainers of the
shoulder straps and slide through
until they lock into place.
2. Insert the tongues into the buckle
assembly until a click is heard.
IMPORTANT: Shoulder and hip straps separate for care and
maintenance, but should always be used together to secure your
child.
Adjusting the Foot Rest
Using the Harness
1
1
1. To adjust the harness.
a. Slide the shoulder adjuster up
or down.
b. Slide the hip adjuster left or
right for a proper adjustment.
NOTE: For a proper adjustment,
harness straps at or above your
child’s shoulders.
Adjusting the Harness
1a
1b
