32
Britax Child Safety, Inc.
Adjusting the Harness
1. Loosen the infant car seat
harness by pressing the
harness adjuster release
button and pulling both
harness straps forward.
Child Seat Functions
2. On the back of the seat,
squeeze the harness
height adjuster and
slide the harness to the
appropriate height.
The infant car seat is assembled with the harness in the
inner loop.
• Inner Loop: For infants
weighing less than 11 lbs (5 kg).
• Outer Loop: For infants
weighing over 11 lbs (5 kg).
IMPORTANT: The harness straps
should be located in the closest
harness height position at or
below the child’s shoulders.
IMPORTANT: Ensure the harness straps are fully secured
on the harness yoke.
Inner Loop
Outer Loop
To Next Page
