Read the safety precautions carefully before installing the unit.
Means improper handling may lead to personal death or severe injury.
Means improper handling may lead to personal injury or property loss.
WARNING
CAUTION
Only suitably trained and qualied personnel should install this equipment.
Installation by other non-qualied persons will result in a poor installation, and
Install this product in strict accordance with this manual.
Maintenance, repair or service must be performed by suitably trained
improper service or repair may lead to electric shock or re.
WARNING
Do not install this product adjacent to areas susceptible to ammable gas leaks.
If ammable gases leak near the control, it may cause a re.
Do not operate with wet hands or let water enter the control. Otherwise,
electric shock may occur.
The wiring should be suitably sized for the control current. Incorrectly sized wiring
may overheat and cause a re.
The specied cables shall be applied in the wiring. Do not allow external forces
to pull on the terminals. Damage to the control and overheating may cause a re.
NOTE
2
3
4
2. INSTALLATION ACCESSORIES
1. SAFETY PRECAUTION
1
1
3
4
1
2
1
1
Don’t install in an area contaminated with heavy oils, vapors or gases that may
cause the control to deform, this may lead to a system malfunction.
Select the appropriate installation location
Preparation before installation
1. Please conrm that the following parts have been supplied.
2. Additional eld supplied requirements.
Wired programmable control
1
Lithium battery
No.
No.
Name
Name
Qty.
Qty.
Remark
Remark
To mount the control
To dismantle the control assembly
Phillips screwdriver
Slotted screwdriver
Installation & owner’s manual
Connecting wiring loom
Stated below are important safety issues that must be obeyed.
possibly electric malfunction, shock, re or personal injury.
and qualied personnel, in accordance with the maintenance instructions
1
Part Number B026004
2
1
1
To connect to the indoor unit
To Next Page
