Brivis UF3 Series User Manual

9
3.2 Heater Dimensions 2PWN26 & 2PWN26 XA
3.3 Service Clearances
Brivis internal heaters installed within the roof space shall be installed on a platform with minimum “Service
Clearances” provided as detailed in Diagram 6. For more information regarding platform requirements refer to
Section 1.9 “Installation of Internal Heaters”.
Model
Dimension [mm]
A B C D E F G H I J K L M
ø N ø R ø S
2PWN26
704
1226
538 722
113
160
445
572 263
269
813
791
1266
125 350 350
2PWN26 XA
704
1226
538 722
113
160
445
572 263
269
813
791
1266
125 400 400
Service
Clearance
Service
Clearance
750 mm
600 mm
6000 mm
750 mm
Platform
Platform
Table 3:
2PWN26 & 2PWN26 XA unit dimensions
Diagram 5.
Diagram 6.
ø Ra
ø Sa
C
A
B
D
E
F
G
H
I
J
L
K
øN
M
