Brivis UF3 Series User Manual

1
1.0 General Guidelines
Brivis Classic heaters are designed to provide a central source of heat for a ducted central heating system. Brivis
Classic heaters should not be installed downstream from an air washer, an evaporative cooler or refrigerative
cooling system. Nor are they designed to be installed on a marine craft, houseboat, or any similar environment.
Brivis Classic heaters must be installed in accordance with these instructions and related regulations, codes,
standards, and authorities. These include but may not be limited to:
Brivis assumes no responsibility for equipment installed in violation of any code, regulations and
these installation instructions.
It is recommended the Brivis "SuperSizeGuide"/Brivisize™ be followed in estimating heating requirements and for
system design that will result in efficient installation and provide a higher level of comfort and economical
operation. For the hourly input and the gas type to be used, see the appliance data label located inside the service
compartment.
1.1 Inspection
This appliance has been inspected and tested at the time of manufacture and packaging, and was released for
transportation without known damage. Upon receipt, inspect the exterior for evidence of rough handling in
shipment. Ensure that the appliance is labelled correctly for the gas it is intended to be connected to. Immediately
report to supplier any discrepancies or damage. Brivis accepts no responsibility for installation of damaged or
incorrect units.
1.2 Unpacking the Heater
Some heaters are supplied on a pallet with a plastic sleeve. To unpack:
• Cut and remove the external plastic packaging and dispose of thoughtfully
• Remove heater from pallet (if supplied)
1.3 Unloading or Lifting the Heater
When unloading or lifting the heater ensure lifting equipment is in good operating condition and capable of lifting
the total load. Be sure there is a clear area to place the heater down, which is within reach of the lifting equipment.
1.4 Gas Inlet Connection
• All piping must be in accordance with AS 5601 and any local gas regulations.
• The connection point for external model heaters is a female G3/4 compression fitting to AS 3688 located
external to the heater cabinet.
• The connection point for internal model heaters is a male G3/4 compression fitting to AS 3688 located in the
heater cabinet.
• A gas cock should be fitted in the gas line adjacent to the heater and in a convenient location so it can be
turned OFF quickly and easily.
• The gas supply should in no way interfere with any servicing of the heater.
Note: All installations should only be carried out by a qualified tradesperson. Installations at altitudes greater than
1000m above sea level may require upgrading of main burner injectors. Please contact the Brivis Customer
Service Centre for advice.
Note:
Secure the heater with suitable lifting equipment if lifting t
o elevated heights, such as onto a house roof.
Note:
The gas supply must be installed by a licensed gas fitter. The gas pipe and gas meter should be sized
so the heater can maintain its required incoming gas pressure at maximum consumption with all other gas
appliances operating at their maximum capacity at the same time as the heater.
• AS 5601 - Gas installations
• AS 4254 - Ductwork for air-handling systems in buildings
• HB 276 – A Guide to Good Practice
• Local Gas and Electricity Authorities
• Brivis “SuperSizeGuide”/Brivisize™
• Local Building Regulations
• Environment Authorities
• Building Code of Australia (BCA)
