2
©2011 Broadcast Electronics
Operating Temp.
Range:
-10ºC to +50ºC
Frequency Stability
(over operating
temperature range):
0.0001%
Signal–to–Noise @ 100
uV Input:
36 kHz BW @ 5.4 kHz Dev
25 kHz BW @ 3.6 kHz Dev
10 kHz BW @ 1.2 kHz Dev
Greater than 57 dB.
Greater than 53 dB.
Greater than 44 dB.
Frequency Response:
± 1.5 dB of the specified bandwidth
Distortion:
2% or less of the specified bandwidth
Spurious Response:
-90 dB
RF Input Impedance:
50 ohms
RF Connector:
Type N-Female
Output Level:
-10 to +11 dBm
Output Impedance:
Balanced, 600 Ohms, 15-pin D-Type connector
Sensitivity:
0.5 microvolts for 20 dB signal-to-noise
2 microvolts for 30 dB signal-to-noise
4 microvolts for 40 dB signal-to-noise
100 microvolts for maximum signal–to–noise,
typically 57 dB or greater.
Metering/Indicators:
Illuminated meter indicates: 1) signal level, 2) decode
level, 3) power supply level, and 4) mono program
output level. LEDs – MAX Signal, ATT Signal,
UNSQUELCHED, POWER supply, AFC LOCK, and F1/F2
on SR–30 Models.
Front Panel Controls:
SIGNAL ATTENUATION, MONO PROGRAM OUTPUT
LEVEL, SQUELCH LEVEL, meter selection control,
HEADPHONE level control.
Power Requirements:
85 to 264 VAC, 47 to 63 Hz
External DC operation on - +10 to +14 VDC
Approximate AC
Current Requirements:
1.5 Amps
Accessory Connector:
15-pin D connector
Weight:
Net 67 pounds. (3.0 kilograms).
Dimensions:
3.5 in. high x 12 in. wide x 15 in. deep.
(8.9 cm. high x 30.5 cm. wide x 38.1 cm. deep.)
Regulatory:
FCC, DOC
