BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
23
9 SR 30 BILL OF MATERIAL
This bill of material uses an indented structure to show relationships of parts into sub assemblies.
Example; all BOM LEVEL 2 parts are contained in the BOM LEVEL 1 part immediately above it.
BOM
LEVEL
PART NO. DESCRIPTION QTY REF. DES.
0 SR30-xxx-
xxx
SR-30,xxx-xxx MHZ,RPU REC,xx KHZ
REC BW,110/220V
..1 339-0031 FILTER/SWITCH, 4 AMP, AC ENTRY 1
..1 400-0600 STRIP,QUIET SHIELD,6.00x.197 1
..1 402-0005 PRESS CLIP,NYLON W/ADHESIVE
BACK
5
..1 402-0006 MT,ADH BACKED,FOR CBL TIES 2
..1 420-0817 ASSY,FEMALE SCREWLOCK 205817-1 4
..1 420-2105 SCREW,2-56X.312,S.S. PH SC 2
..1 420-3706 SCREW,M3 X 6,PHILLIPS PAN HEAD,SS 2
..1 420-4103 SCREW,4-40X.187,S.S. PH 2
..1 420-4105 SCREW,4-40X.312,S.S. PH 2
..1 421-0102 10-32 KEP NUT 1
..1 421-1111 RIV,1/8X.422L .126-.187GR CLOS 8
..1 421-4008 4-40 KEP NUT 2
..1 421-8028 NUT,JAM,1/2-28 UNEF-2B 1
..1 422-6106 SCREW,SEMS 6-32 X 3/8 PAN PH. ST." 2
..1 423-4002 #4 LOCK S.S. SPLIT 4
..1 423-9002 WASH,INT TOOTH,1/2 1
..1 469-0021 FINGER STOCK,LAIRD 97-550,24 LONG" 1.156
..1 469-0022 FINGER STOCK,LAIRD 97-654,12 LONG" 0.1
..1 471-5347 ENCLOSURE,CONVERTER,MARTI SR
SERIES RECEIVERS (NOTE)
1
..1 471-5348 PANEL,REAR,SR30/SR40A 1
..1 471-5349 COVER,SR30/SR40A 1
..1 471-5350 CHASSIS,SR30/SR40A 1
..1 471-5385 FILLER,REAR,SRPT-30 1
..1 500-022 Screw, 6-32 x 3/8 phillips pan head M/S
nickel plated"
2
..1 500-188 Screw, 4-40 x 3/8 phillips,flat head,black
oxide"
2
..1 500-210 Screw,SEMS 4-40x1/4 Phil Pan Head MS
Blk Zinc(external lock)
67
..1 510-090 Cable Ties, 4 Panduit PANPLT1M-M
MS3367-4-9"
2
..1 510-132 Handle Assy., black w/black plated steel
hdwe #1879-376-370
1
..1 510-205 BUMPER, BRUCE PLASTICS 0772-0014
BLACK
8
..1 513-036 STANDOFF,1/4HEX x 0.5"LONG,4-
40,M/F"
2
..1 540-0018 POWER SUPPLY, 40 WATT, 12 VOLT 1
..1 594-0503 LABEL, DANGER-HAZARDOUS
VOLTAGE
2
