26
BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
©2011 Broadcast Electronics
....2 145-683 Resistor, 68k ohm 1/4 watt 1% metal film
Mepco SFR25
1 R9
....2 145-684-1 Resistor, 681k ohm 1/4 watt 1% 2 R10,R24
....2 145-822 Resistor, 8.25k ohm 1/4 watt 1% metal film
Mepco SFR25
1 R12
....2 200-0009 DIODE,ZENER,1N 4739A 1 D6
....2 203-4148 DIODE,1N4148 2 D4,D5
....2 211-3904 TSTR,2N3904 1
....2 215-103 CAPACITOR, .01 uFD 2.5% 100V
POLYPRO
1 C2
....2 215-473 CAPACITOR, .047 uFD 2.5% 100V
POLYPRO
2 C4,C5
....2 219-200 CAPACITOR ELECTROLYTIC 22UF 25V 5 C3,C6,C7,C9,C10
....2 219-251 CAP,ELECTROLYTIC,220uF 25V,AXIAL,-
20/+50%
1 C13
....2 226-274 Cap.,.27 mf 100v 10% polypro CD
MTC1P27K OR Bishop C21B274K
1 C1
....2 400-293 IC, DUAL DIFFERENTIAL COMPARATOR 1 IC2
....2 400-740 IC, JFET INPUT OPAMP, TL084CN 1 IC1
....2 410-754 Diode, zener Motorola 1N754A 6.3v 1 D3
....2 412-494 DIODE, GERMANIUM 1N270 (note) 1 D1
....2 414-007 DIODE, RECITIFIER,1N4007 1 D8
....2 550-123 Connector, 10 pin header (cut from 550-
162)
1 P1
......3 550-162 Connector, 24 pin break-away (straight)
Molex 26-48-6248
0.417
....2 550-161 IC Socket, 16 pin Aries 16-3518-11 1 XK1
....2 570-035-1 Relay, Aromat HB2E-DC12V 1 K1
....2 800-229B PC Board, Decode RPU Receiver 1 PCB
..1 913-2134 ASSY,PCB,BW SELECTABLE AUDIO
BD.(SBCM)
1
....2 006-1085 CAP,ELECTRO,100 UF,10%,35V,SMD 12 C1,C2,C12,C13,C14,
C17,C18,C43,C44,
C45,C46,C47
....2 006-2285-
500
CAP,ELECTRO,220UF,20%,50V,SMD 1 C49
....2 007-0683 CAP CERAMIC, 0.068uF, 50v, SMD, 0805 1 C31
....2 007-1003-
050
CAP,1000PF,0805,5%,50V 3 C8,C30,C42
....2 007-1034 CAP,CER,0.01uF,50V,10%,SMD 3 C7,C15,C16
....2 007-1034-
026
CAP,CER,10000 PF,1%,25V,1206,SMD 1 C6
....2 007-1203-
500
CAP, CER, 1200 PF, 50V, 5%, SMD 3 C10,C29,C41
....2 007-1204-
050
CAP,.012UF,0805,5%,50V 1 C19
....2 007-1503-
050
CAP,1500PF,0805,5%,50V 3 C11,C28,C40
....2 007-1504-
050
CAP,.015UF,0805,5%,50V 1 C36
....2 007-1803-
050
CAP,1800PF,0805,5%,50V 2 C27,C39
