Broadcast Electronics Marti Electronics SR-30 - Page 41

BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
31
......3 400-196 IC, SMT, 1.5A STEP-UP REGULATOR 1 U24
......3 401-164 IC, SMT, 8-Bit Ser In, Par Out SR Phillips
74HC164D
2 U5,U6
......3 401-165 IC, 8-Bit Ser/Par In, Ser Out SR Phillips
74HC165D
5 U1,U2,U3,U4,U20
......3 401-275 IC,SMT,OP-AMP,LOW NOISE,HIGH
AUDIO BW
5 U15,U16,U17,U18,
U19
......3 401-374 IC, OCTAL D FLIP-FLOP W 3-ST OUT 2 U7,U12
......3 411-914 DIODE, SMD 1N4148 1 D15
......3 413-1206 CHIP,TEST POINT,1206,SMD 15 TP1,TP2,TP4,TP5,
TP6,TP8,TP10,TP11
,TP12,TP13,TP14,
TP15,TP16,TP17,
TP18
......3 417-0003 CONN,HEADER 3 PIN 1 J12
......3 417-0182 CONN,HDR,26 PIN,LATCHED 1 J2
......3 417-0200 CONN,HEADER 20 PIN 0.2 J11
......3 418-120 DIODE, SMT, 1A, SCHOTTKY RECTIFIER 1 D16
......3 418-1601 CONN,MALE,16-PIN,LATCH,PCB MT 2 J1,J4
......3 418-1601-
001
CONN,MALE,16-PIN,LONG LATCH,PCB
MT
1 J13
......3 418-2602-
001
CONN,HEADER,26
PIN,LATCH/EJECT,PCB
1 J3
......3 418-451 Diode, SMT, Zener, 5.1V Motorola
BZX84C5V1LT1
1 D11
......3 426-4008 STOFF,PEM 4-40 KFSE-440-12 2
......3 439-041 TRANSISTOR, SMT, GENERAL
PURPOSE, NPN
8 Q1,Q2,Q3,Q4,Q5,Q6
,Q7,Q9
......3 510-196 SUBMINIATURE LAMP, LUMEX IFL-
LX2162-16T
2 B1,B2
......3 513-2130 PCB,BLANK,SR30/SR-40A FRONT
PANEL
1
......3 530-059 SWITCH, ROTARY 1 S2
....2 943-2130-
001
ASSY,WIRE
HARNESS,HEADPHONE,MARTI
REC,FRONT PANEL (SBCM)
1
......3 402-0051 TY-RAP, W/FLAG 1
......3 417-0138 HSNG,MOD IV 4 POS 87499-7 AMP 1
......3 417-8766 CONTACT,CRIMP,MOD-IV 87809-1 3
......3 580-050 Wire, UL1061 22/7 OS-1 White/Red 0.25
......3 580-053 Wire, UL1061 22/7 OTC White/Black 0.25
......3 601-2209 WIRE,AWG22,19/34 WHT 0.25
..1 973-0100 KIT,ACCESSORY,SR30 1
....2 550-030 CONNECTOR, D-SUB 15 PIN FEMALE 1
....2 550-180 Connector, locking hood Keltron HD-15-10 1
....2 580-116 Power Cord, Black Detachable Power
Dynamics
1
....2 973-9999 KIT,BIND+MAN,SR30/SR40A 1
......3 597-8104 INSTRUCTION MANUAL, SR 30/SR 40A
RPU RECEIVER
1
......3 597-9996 MAN,COVER,MARTI REAR 1
......3 597-9997 MAN,COVER,MARTI FRONT,
W/WINDOW
1
