BOM
LEVEL PART NO. DESCRIPTION QTY REF. DES.
63
..1 913-
2132-450
ASSY,DUAL WIDE-BAND
CONVERTER,450 MHZ (NOTE)
1
....2 270-407-
1
Capacitor,SMT,size
1206,4.7pF,COG,100V Kemet
C1206C479C1GAC
3 C61,C62,C63
....2 350-192 INDUCTOR, 12.5nH, SMT, 1206 2 L10,L13
....2 350-194 INDUCTOR, 18.5nH, SMT, 1206 2 L11,L12
....2 360-0436 FILTER, HELICAL BANDPASS, F=436M 2 FL2,FL3
....2 360-0449 FILTER, HELICAL BANDPASS, F=449M 2 FL4,FL5
....2 360-0455 FILTER, HELICAL BANDPASS, F=455M 1 FL1
....2 360-0461 FILTER, HELICAL BANDPASS, F=461M 2 FL8,FL9
....2 360-0474 FILTER, HELICAL BANDPASS, F=474M 2 FL6,FL7
....2 400-420 IC, VCO, 370-420 MHZ 1 U31
....2 407-0503 EMI SHIELD,MARTI CONVERTER INPUT 1
....2 427-0061 CONNECTOR, N, PCB, STRAIGHT, PNL
MTG
1 J4
....2 913-2132 ASSY,PCB,DUAL WIDE-BAND
CONVERTER (SBCM)
1
......3 006-1085 CAP,ELECTRO,100 UF,10%,35V,SMD 9 C94,C95,C88,C105
,C130,C124,C125,
C89,C156
......3 006-
4775-350
CAP,ELECTRO,47UF,20%,35V,SMD 1 C134
......3 007-
0470-006
CAP,470pF,50v,10%,0603 2 C137,C121
......3 007-1022 CAP,CER,100pF,50V,2%,SMD 3 C120,C117,C118
......3 007-1024 CAP,CER,.001uF,50V,10%,SMD 1 C115
......3 007-1044 CAP,CER,0.1uF,50V,10%,SMD note 14 C1,C4,C5,C6,C7,
C8,C13,C14,C15,
C16,C17,C111,
C119,C34
......3 007-
1813-050
CAP,CER,180 PFD,5%,50V,1206,SMD 1 C102
......3 007-3300 CAP,CER,3.3PF,50V,.25pF,SMD 1 C116
......3 007-3312 CAP,CER,33pF,50V,2%,SMD 4 C2,C3,C110,C114
......3 007-
4700-500
CAP,CER,4.7pF,50V,.25pF,SMD 1 C113
......3 011-
7.3728
Crystal,SMT,7.3728 MHz, 50ppm, Epson
MA-506-7.3728M-C2
1 X1
......3 012-280-
1
TCXO, SMT, 12.800 MHZ, 1PPM 1 U29
......3 070-1054 CAP,TANT,1uF,35V,10%,SMD 36 C18,C9,C10,C23,
C24,C25,C31,C32,
C29,C47,C50,C51,
C53,C54,C57,C58,
C70,C71,C66,C67,
C78,C79,C73,C74,
C87,C145,C96,C98
,C93,C131,C126,
C128,C90,C123,
C42,C154
......3 070-1064 CAP,TANT,10uF,35V,20%,SMD 1 C138
