BroadLink BL3383-P User Manual

- 4 -
BLE @4dBm
150
2.2. Working Environment
Please refer to Table 2 for working environment data.
Table 2 BL3383-P Working Environment Data
Symbol
Description
Min.
Max.
Units
Ts
Storage temperature
-40
125
℃
TA
Ambient operating temperature
0
85
℃
Vdd
Supply voltage
3.0
3.6
V
Vio
Voltage on IO pin
0
3.6
V
3. Radio Specifications
3.1. Basic Radio Specification
Please refer to Table 3 for radio specification.
Table 3 BL3383-P Radio Specification
Radio range
2402-2480MHz
Wireless standards
IEEE 802.11 b/g/n
Radio output (conductive)
802.11b:18.6
±
1.5dBm@11Mbps
802.11g: 16.81
±
1.5dBm@54Mbps
802.11n: 16.9
±
1.5dBm@MCS7/HT20
BLE: 4
±
2dBm
Antenna type
Internal: PCB antenna
External: Not supported
Receiving sensitivity
802.11b≦-89dBm@11Mbps
802.11g≦-76dBm@54Mbps
802.11n/HT20≦-73dBm@MCS7
Stack
IPv4, TCP/UDP/FTP/HTTP/HTTPS/TLS/mDNS
