BroadLink BL3383-P User Manual

- 7 -
Modulation Type
OFDM
Frequency range
2412 MHz~ 2462 MHz
Channel
CH1 to CH11
Data rate
MCS0/1/2/3/4/5/6/7
Table 11 Transmitting performance under IEEE802.11n with 20MHz
TX Characteristics
Min.
Typical
Max.
Unit
Power@HT20, MCS7
15.5
dBm
Frequency Error
-10
+10
ppm
EVM@HT20, MCS7
-30
dB
Transmit spectrum mask
Pass
Table 12 Receiving performance under IEEE802.11n with 20MHz
RX Characteristics
Min
.
Typical
Ma
x.
Unit
MCS7 Input Level Sensitivity
Minimum Input Level (FER≦10%)
-73
dBm
4. BL3383-P Hardware Information
4.1. PIN Sequence
Please refer to Fig 1 for the pin sequence.

BroadLink BL3383-P Specifications

General

Brand	BroadLink
Model	BL3383-P
Category	Wireless Router
Language	English
