Broan SPE136SS - Prepare the Hood

INSTALLATION MANUAL
INSTALLATION
9
Prepare the Hood
1 ] If present, remove all protective polyfilm from the hood and/or parts.
2 ] Using the finger cup, remove the grease filters from the hood by pushing down  and tilting
filters out .
3 ] Remove both fillers by removing the 3 screws holding each one of them. Slide each one
towards the center of the hood and tilt it up to remove it completely. Set the fillers and screws
aside.
B
C
c
d
