BROOD DRNX SLM - Components; Specifications

5DRNX SLM BY BROOD
COMPONENTS
1 – Tap Button
2 – Infusion Button
3 – Nozzle
4 – Exterior
5 – Inlet Connector
6 – Main ON/OFF Switch
7 – Legs
8 – Forward Plate
9 – Rear Plate
10 – Side Panel(s)
11 – Power Cord
12 – Vents/Exhaust
13 – Beverage Tube
14 – Elbow Connectors
15 – Pre-Filter
16 – BROOD Beverage Container
17 – Inlet for Container
18 –Thermostat
19 – Calibration Knob
20 – Inlet Air
SPECIFICATIONS
Width: 9.00in Power Supply: 100-120V/60Hz; 200-240V/50Hz
Height: 14.75in Nominal Power: 334W
Depth: 18.25in Amps: 3.5A
Weight: 77lbs Refrigerant: R513a/200g
Dispensing Capacity: 1.7L/min (0.4gpm) High Side: 300PSI/Low Side:60
Coee Temp at Tap: 2°C (36°F) For Commercial Use Indoors
3
9” 18.25”
14.75”
4
14
16
17
15
14
9
12
10
8
7
5
20
13
6
11
18
19
1
2
