LOCATION OF PARTS AND CONTROLS
1. Volume -
2. Power/Pairing Button
3. LED Ring
4. Volume +
LOCATION OF PARTS AND CONTROLS
5. Wi-Fi Set Up/Reset Button
6. Wi-Fi Mode LED Indicator
7. Wi-Fi Status LED Indicator
8. Bluetooth
®
Mode LED Indicator
9. LED Ring On/Off button
10. Aux In Port
11. DC In Port
12. AC Adapter
