Broseley eVolution 5 - Smoke Control Area Assembly

Assembly for Smoke Exemption
When installing this appliance into a smoke control area you will need to change the
washer that sits behind the air slider to the smoke exempt washer (supplied). The smoke
exempt washer ensures a constant supply of combustion air to meet smoke exempt
requirements.
MS07-11 Issue 2 12
