Brother DCP-195C

List3(ENGINE)
REF No. CODE Q'TY DESCRIPTION REMARKS
1 LS6537001 1 ENGINE UNIT (SP),
DCP195C/DCP197C/DCP365CN/DCP373CW/DCP375CW/DCP377CW/
MF
C
2
53C
W
/
MF
C
2
55C
W
/
MF
C
2
55C
WE
/
MF
C
2
5
7
C
W
/
MF
C
2
95C
N
1 LX1876001 1 ENGINE UNIT
(
SP
),
DCP395CN/MFC495CW/MFC795CW
1-1 LS4301001 1 STAR WHEEL HOLDER
1-2 LS4303001 1 PLATEN F ASSY,
DCP195C/DCP197C/DCP365CN/DCP373CW/DCP375CW/DCP377CW/
MF
C
2
53C
W
/
MF
C
2
55C
W
/
MF
C
2
55C
WE
/
MF
C
2
5
7
C
W
/
MF
C
2
95C
N
1-2 LS4304001 1 PLATEN M ASSY
,
DCP395CN/MFC495CW/MFC795CW
1-3 LX3629001 1 CARRIAGE MOTOR CHG
1-4 LP1471001 1 RF ENCODER DISK
1-5 LS4249001 1 INNER CHUTE ASSY
1-5-1 LS4251001 1 REGISTRATION SENSOR ACTUATOR
1-6 LT0466001 1 SENSOR HARNESS UNIT
1-7 LS4198001 1 TIMING BELT
1-8 LS4260001 1
A
SF GEAR SHAFT OUTER
1-9 LX0126001 1
A
SF ROLLER 9 UNIT ASS
Y
1-10 LS4467001 1 ENCODER STRIP
1-11 00030060
6
2 SCREW BIND M3X6
1-12 00002120
6
1 SCREW BIND M2X12
1-13 LS4120001 1 PE ACTUATOR 9 ASSY add
1-14 LS4075001 1 PE ACTUATOR SPRING add
2 LS425300
2
1 JAM CLEAR COVER
,
DCP195C/DCP197
C
2 LS425300
7
1 JAM CLEAR COVER
,
DCP365CN
2 LS4253003 1 JAM CLEAR COVER, DCP373CW/DCP375CW/DCP377CW/DCP395CN/
MFC253CW/MFC255CW/MFC255CWE/MFC257CW/MFC295CN/MFC495CW/MFC795CW
3 LS4383001 1 HEAD COVER
4 LX0376001 1 TUBE SUPPORT PLATE
5 LS4469001 1 TUBE SUPPORT WIRE
6 LS6543001 1 CARRIAGE PCB ASSY
(
SP
)
7 LS6544001 1 MAINTENANCE UNIT
(
SP
)
7-1 LS4091001 1
A
SF MOTOR
7-2 LS4098001 1 SWITCHING LEVER GUIDE
7-3 LS4375001 2 SCREW PAN
(
S/P WASHER
)
M3X5
8 LS5775001 1 EARTH SPRING
9 08731101
6
3 TAPTITE CUP B M3X10
8CAJ06/11/13/15/17/33
36/35/37/41/43/47
DCP195C/DCP197C/DCP365CN
DCP373CW/DCP375CW/DCP377CW/DCP395CN
MFC253CW/MFC255CW/MFC255CWE/MFC257CW
MFC295CN/MFC495CW/MFC795CW
- 6 -
