Brother HL-1202 Service Manual

vi
Confidential
SAFETY INFORMATION
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injuries.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injuries.
IMPORTANT
IMPORTANT indicates a potentially hazardous situation which, if not avoided, may result
in damage to property or loss of product functionality.
Prohibition icons indicate actions that must not be performed.
Electrical Hazard icons alert you to possible electrical shock.
Fire Hazard icons alert you to the possibility of fire.
Hot Surface icons warn you not to touch product parts that are hot.
Note Notes tell you how you should respond to a situation that may arise or give tips about
how the operation works with other features.

Brother HL-1202 Specifications

General

Product color	Black, White
Color	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Custom media width	148 - 216 mm
Custom media length	148 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	65 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	17 - 28 lbs
Total input capacity	150 sheets
Total output capacity	50 sheets
Standard interfaces	USB 1.1, USB 2.0
Mac operating systems supported	Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 10.7 Lion, Mac OS X 10.10 Yosemite
Server operating systems supported	Windows Server 2008 x64, Windows Server 2012 x64, Windows Server 2008 R2, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2012 R2 x64
Windows operating systems supported	Windows Vista Home Basic, Windows 7 Home Basic, Windows 8 Enterprise, Windows 7 Enterprise, Windows Vista Home Basic x64, Windows 7 Home Basic x64, Windows 8 Enterprise x64, Windows Vista Home Premium, Windows 7 Home Premium, Windows 8.1, Windows Vista Home Premium x64, Windows 8.1 x64, Windows Vista Business, Windows 7 Professional, Windows 8.1 Pro, Windows Vista Business x64, Windows 7 Professional x64, Windows 8.1 Pro x64, Windows Vista Enterprise, Windows 7 Ultimate, Windows 8.1 Enterprise, Windows Vista Enterprise x64, Windows 7 Ultimate x64, Windows 8.1 Enterprise x64, Windows XP Home, Windows Vista Ultimate, Windows 8, Windows XP Home x64, Windows Vista Ultimate x64, Windows 8 x64, Windows XP Professional, Windows 7 Starter, Windows 8 Pro, Windows XP Professional x64, Windows 7 Starter x64, Windows 8 Pro x64, Windows 7 Enterprise x64
Printing colors	Black
Maximum duty cycle	10000 pages per month
Recommended duty cycle	250 - 1800 pages per month
Number of print cartridges	1
Page description languages	GDI
Sustainability certificates	ENERGY STAR
Sound pressure level (printing)	51 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1056 W
Power consumption (off)	0.28 W
Power consumption (standby)	0.5 W
Power consumption (printing)	380 W
Power consumption (PowerSave)	40 W
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Mobile printing technologies	-

Weight and Dimensions

Depth	238 mm
Width	340 mm
Height	189 mm
