4. FIXING UNIT
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LJ5829001 1 FIXING UNIT, 115V (SP)
1 LJ5830001 1 FIXING UNIT, 230V (SP)
1-2 LJ5682001 1 CLEANER ASSY E
1-3 UH3635001 1 CLEANER SPRING 30
1-4 LJ5684001 1 HEAT ROLLER 25
1-5 UL8908001 2 HR BEARING 25
1-6 LJ5685001 1 HALOGEN LAMP, 115V
1-6 LJ5695001 1 HALOGEN LAMP, 230V
1-8 LJ5276001 2 EJECT PINCH ROLLER HOLDER L
1-9 LJ5277001 2 EJECT PINCH ROLLER HOLDER R
1-10 LJ5278001 8 EJECT PINCH ROLLER
1-11 LJ5279001 4 EJECT PINCH SPRING
1-12 LJ5280001 4 SEPARATE CLAW ASSY 2
1-13 087310615 4 TAPTITE, CUP B M3X6
1-14 LJ5686001 1 THERMISTOR ASSY
1-15 085311216 1 TAPTITE, BIND B M3X12
1-16 LJ5734001 1 EJECT ACTUATOR 2
1-17 LJ5732001 1 EJECT ACTUATOR SPRING 2
1-18 LJ5736001 1 ACTUATOR HOLDER
1-19 LJ5735001 1 EJECT ACTUATOR 3
1-20 085311015 6 SCREW,BIND B TITE 3X10
1-21 UL8916001 2 PR BEARING
1-22 LJ5690001 2 PR SPRING
1-23 LJ5268001 5 CLEANER PINCH ROLLER ASSY
1-24 LJ5287001 1 PRESSURE ROLLER 25
1-25 UL8920001 1 PAPER EJECT ACTUATOR
1-26 UL8921001 1 EJECT ACTUATOR SPRING
1-27 087312015 1 TAPTITE, CUP B M3X20
2 Z07200001 1 TAPTITE, PAN B M3X10
3 LJ4740001 2 SHOULDER SCREW
4 LJ8841001 1 JAM SENSOR PCB ASSY B512096-1
5 LJ4432001 1 TAPE 32X12
6 085311015 1 SCREW,BIND B TITE 3X10
- 5 -
