Brother HL-5350DN Quick Setup Guide

24
For Network Users (HL-5350DN only)
Web Based Management
(web browser)
The Brother print server is equipped with a web server
that allows you to monitor its status or change some
of its configuration settings, using HTTP (Hyper Text
Transfer Protocol).
a Start your web browser.
b Type http://printer ip address/
into your browser.
(Where printer ip address is the IP
Address or the print server name)
 For example: http://192.168.1.2/
(if the printer’s IP Address is 192.168.1.2.)
Reset the network settings to the
factory default
To reset all network settings of the print server to its
factory default, follow the steps below.
a Turn off the printer.
b Make sure that the front cover is closed and the
power cord is plugged in.
c Hold down Go as you turn on the power switch.
Keep Go pressed down until the all LEDs light
up and then Status LED turns up. Release Go.
Make sure that all the LEDs turn off.
d Press Go six times. Make sure that all the
LEDs light up to indicate the print server has
been reset to its default settings.
The printer will restart.
Print the Printer Settings Page
The Printer Settings Page lists all the current printer
settings, including network settings. To print the
printer settings page:
a Make sure that the front cover is closed and the
power cord is plugged in.
b Turn on the printer and wait until the printer is
in the Ready state.
c Press Go three times within 2 seconds. The
printer will print the current printer settings
page.
Note
• The login name for the Administrator is ‘admin’
(case sensitive) and the default password is
‘access’.
• We recommend Microsoft Internet Explorer
6.0
®
(or greater) or Firefox
®
1.0 (or greater) for
Windows
®
and Safari
®
1.3 (or greater) for
Macintosh
®
. Please also make sure that
JavaScript and Cookies are always enabled in
whichever browser you use. To use a web
browser, you will need to know the IP Address
of the print server. The IP Address of the print
server is listed on the Printer Settings Page.
See Chapter 10 of the Network User's
Guide.
Note
If the IP Address on the Printer Settings Page
shows 0.0.0.0, wait for one minute and try again.

Brother HL-5350DN Specifications

General

Color	No
N-up printing	4, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	32 MB
Processor model	NEC VR5500
Maximum internal memory	544 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features	10/100 Base-TX
Power consumption (active)	675 W
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)	75 W
Power consumption (PowerSave)	6 W
Package weight	11500 g

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 246 mm
