LOWER/UPPER THREADING
26
j
Cut the thread, and then remove the bobbin.
■ Winding the Bobbin Using the Spool Pin
The main spool pin cannot be used to wind the
bobbin while sewing. For details, see “Using the
Supplemental Spool Pin” on page 24.
a
Turn on the machine.
b
Open the top cover.
c
Align the groove in the bobbin with the spring
on the bobbin winder shaft, and then slide the
bobbin onto the shaft.
a Groove in bobbin
b Spring on bobbin winder shaft
d
Pivot the spool pin so that it angles upward,
and then place the spool of thread on the
spool pin.
* Make sure that the thread unwinds from the front.
a Spool cap
b Thread spool
c Spool pin
e
Slide the spool cap as far as possible onto the
spool pin, and then return the spool pin to its
original position.
f
While holding the thread from the spool with
both hands, pull the thread through the lower
notch in the thread guide plate, then through
the upper notch.
a Lower notch in the thread guide plate
b Upper notch in the thread guide plate
Note
When removing the bobbin, pull up only on the bobbin.
Do not pull on the bobbin winder seat, otherwise it may
become loose, resulting in damage to the machine.
CAUTION
• Winding the bobbin thread improperly may cause
the thread tension to loosen, breaking the needle
and possibly resulting in injury.
3
4
5
6
7
9
1
o
l
8
2
a
b
a
b
c
a
b
